– On-board 1 K-sample A/D FIFO
– 16-bit A/D resolution (DAQ-2205 & DAQ-2206)
– 12-bit A/D resolution (DAQ-2204)
– Up to 3 MS/s sampling rate (DAQ-2204)
– Supports a 32-bit 3.3 V or 5 V PCI bus
– 64-CH single-ended or 32-CH differential analog inputs
– Programmable gains: x1, x2, x4, x5, x8, x10, x20, x40, x50, x200 (DAQ-2204), and x1, x2, x4, x8 (DAQ-2205 & DAQ-2206)
– Bipolar or unipolar analog input ranges
