– PXI specifications Rev. 2.0 compliant
– 3U Eurocard form factor, CompactPCI compliant (PICMG 2.0 R3.0)
– 96-CH single-ended or 48-CH differential analog inputs
– Up to 3 MS/s sampling rate
– 12-bit A/D resolution
– On-board 1k-sample A/D FIFO
– Bipolar or unipolar analog input ranges
– Programmable gains of x1, x2, x4, x5, x8, x10, x20, x40, x50, x200
